Enhance Your 1FZ-FE Engine with the Turbo Oil and Water Line Kit

This kit contains all the fittings you need to hook up water and oil feeds to your 1FZ-FE equipped with a GTX35, Turbosmart TS-2 or similar Turbo. Takes all the hard work out of having to order a bunch of individual fittings, or make continuous trips to a performance wholesaler for fittings!

Kit Components:

• RWF-732-06BK x 2: Metric Male M14x1.5 to Male Flare AN-6
• RWF-203-06SS x 2: Teflon Hose Fitting AN-6 90 Degree
• RWF-201-06SS x 2: Teflon Hose Fitting AN-6 Straight
• RWF-717-06-05BK x 2: AN-6 Male Flare to 5/16 Barb
• RWF-203-04BK x 1: Teflon Hose Fitting AN-4 90 Degree
• RWF-201-04BK x 1: Teflon Hose Fitting AN-4 Straight
• RWF-817-04-02TBK x 1: Male Flare AN-4 to Male BSPT 1/8
• RWH-200-06-1M x 2: Braided Teflon E85 Hose AN-6 (1 Meter Length)
• RWH-200-04-1M x 1: Braided Teflon E85 Hose AN-4 (1 Meter Length)
• RWF-809-02SS: Stainless Oil Pressure Adapter 1/8BSPT

Optional Drain Kit:

Add on Oil Drain Kit for a simple installation process.

Updated Kit with All Stainless Hose Ends:

Our updated kit now features all stainless hose ends for enhanced durability and performance.

DIY Style Kit:

The hoses provided are 1 meter in length and can be easily trimmed to your desired size during installation. If you prefer pre-assembled hoses and fittings, contact us for this service at an additional cost.
