Spool Forged Conrods suitable for Toyota LandCruiser 1FZ-FE

Spool Forged Conrods suitable for Toyota LandCruiser 1FZ-FE

A set of Spool forged H-beam conrods for the 1FZ-FE 4.5L inline six. They’re a direct fit for the factory rods and come with ARP 2000 rod bolts as standard, so they suit a rebuild where the bottom end needs to take more than stock power.

🚗 Suitable for:

• Toyota LandCruiser 70 Series FZJ70 FZJ75 FZJ78 FZJ79 1FZ-FE 4.5L Petrol 1992-2006
• Toyota LandCruiser 80 Series FZJ80 1FZ-FE 4.5L Petrol 1992-1998
• Toyota LandCruiser 100 Series FZJ105 1FZ-FE 4.5L Petrol 1998-2002

📦 What’s Included:

• 6 x brand new Spool forged conrods, weight matched as a set
• ARP 2000 rod bolts fitted

🔧 Fitment Details:

• Direct fit for the 1FZ-FE (4476cc inline six, DOHC, 4 valves per cylinder)
• Caps are dowelled, so they locate the same way every time they go back on
• Rod bolts can be upgraded to ARP L19, and a set of ACL Race bearings can be added in STD, 0.025 or 0.25 sizes

⚙️ Why Choose Spool:

• Forged from 4340 high tensile steel in a two piece forging, quenched and heat treated, then shot peened
• Hardness of HRC36-42
• Every rod is X-ray and sonic tested and magnafluxed
• Vacuum degassed to remove impurities in the steel
• Sets are weight matched to within 1 gram

Technical Specifications:

• Material: 4340 forged steel
• Design: H-beam, two piece forging
• Hardness: HRC36-42
• Fasteners: ARP 2000 (ARP L19 optional)
• Weight matching: plus or minus 1 gram

❓ FAQs:

Q: Do these come with bolts?

A: Yes. ARP 2000 rod bolts come with every set. ARP L19 bolts are an optional upgrade.

Q: Do I need new bearings?

A: New bearings are the norm with new rods. ACL Race bearings can be added in STD, 0.025 or 0.25 sizes.

Q: Will they fit the 1HZ or 1HD-FTE?

A: No. These are made for the 1FZ-FE petrol only.
